Energy Saving Polyurethane Spray Machine For Wall Roof Waterproof
Anti Corrosion
Polyurethane Spray Machine Applications
1. Polyurethane spray on wall & roof,
2. Polyurea spray for waterprrof & anticorrosion,
3. Construction seam filling,
7. Car roof spray insulation,
8. Highway, railway, automobile, watercraft, mining petroleum,
electrical industry, food industry etc.
Polyurethane Spray Machine Describe:
- The equipment has obtained CE certification, safe and environmental
protection.
- Having the proprietary property rights in design and production,
several national patents have been applied and approved.
- The perfect coaxial structure design of the horizontal booster pump
reduces greatly the abrasion of the sealing. There is no pressure
difference during operation and the commuting pressure fluctuation
value is ideal and stable.
- The design and application of the reset function when shut down
realizes the dual protection.
- The dual filters of the equipment for both high and low pressure
and the filter of the nozzle realize the triple filtration
protection for the raw material and reduce the blocking.
- The special armoured temperature sensor inside the heater can
collect the temperature signal at any time, hence the overshooting
value for heating is well controlled.
Polyurethane Spray Machine Parameters
| Product Name: | Energy Saving Polyurethane Spray Machine For Wall Roof Waterproof
Anti Corrosion | The Ratio Of Raw Material: | 1:1 |
|---|
| Viscosity Range Of Raw Material: | 200-2000CPS(under Working Temperature) | Max Working Pressure: | 20Mpa (200bar) |
|---|
| Max Fluid Temperature: | 80°C (176°F);Heating Power:8KW | Max Output: | 4-8kg/min (19.8 Lb/min) |
|---|
| Heater Power: | 3000W×2 | Pipeline Insulation Heating Power: | 2000W |
|---|
| Spray gun clean | Self-clean by air | Voltage (Optional) | 1-ph 220V 50Hz or 3-ph 380V 50Hz |
|---|
| Pneumatic source | 0.5-0.8Mpa 1m³/min (73-116psi 35 cu ft) | P2 spray gun | 1 pc |
|---|
| Air pipe:1 set | Spare parts and tools:1 set | Package size (L×W×H) | 1050*1100*1200mm |
|---|
| Net weight/Gross weight | 90k/150kg | Feature | high speed |
|---|
Use area:
Building exterior wall, cold storage, automobile, chemical storage
tank, workshop workshop, grain depot, farm shed and so on.
Picture:
